SB72: Schneider Electric AccuSine+ Active Harmonic Filter, 480 V 3-Phase, Wall-Mounted Power Quality Correction Unit – PF-1 Electrical Room

This lot, SB72, features a Schneider Electric AccuSine+ active harmonic filter, used to improve power quality and protect sensitive electrical systems from voltage distortion and poor power factor. The AccuSine+ system continuously monitors load current and dynamically compensates for harmonic content, neutral current, and reactive power, ensuring optimal performance and compliance with IEEE 519 standards. It is installed in the PF-1 Electrical Room, adjacent to the main distribution equipment, and serves as part of the facility’s advanced electrical management infrastructure for high-efficiency operation of automation, HVAC, and lighting loads. Specifications (per Schneider Electric data for AccuSine+ series) Manufacturer: Schneider Electric Model: AccuSine+ Active Harmonic Filter Voltage Rating: 480 V, 3-phase Configuration: Wall-mounted enclosure Frequency: 60 Hz Function: Harmonic mitigation Power factor correction Load balancing and voltage stabilization Control Interface: Integrated touchscreen HMI (front panel display) Enclosure Type: UL Type 1 (ventilated indoor installation) Location: PF-1 Electrical Room Installation: Conduit-fed, hardwired integration with main electrical bus Compliance: UL 508A IEEE 519 harmonic compliance CE / CSA listed Functional Overview Dynamic Harmonic Filtering: Cancels harmonic currents (up to the 50th order) in real-time. Power Factor Correction: Automatically adjusts reactive power to maintain near unity power factor. Load Balancing: Distributes load currents evenly across phases. Energy Efficiency: Reduces heating losses, improving transformer and system efficiency. Touchscreen Monitoring: Built-in HMI display for live data, diagnostics, and event logging. Communication Options: Modbus TCP/IP, Ethernet for system integration and SCADA control.
