SB6022b: Evaporator 3B – Trenton TVS035M8-HT4B-A3CQ78 Vertical Air-Cooled Evaporator (~3.5 HP Scroll Circuit, 460 V 3-Phase) Connected to RCU 2 – Located Southwest Corner of 37 °F Cold Pack Room

This listing covers EVAP 3B – Trenton TVS035M8-HT4B-A3CQ78, a vertical-style air-cooled evaporator paired with RCU 2, installed on the southwest wall of the 37 °F Cold Pack Room.

Part of Trenton’s TVS series, this evaporator is engineered for compact footprint, efficient air movement, and consistent temperature control in cold-pack and food-processing applications.

The TVS035M8 configuration includes a 3.5 HP Copeland Z-series scroll compressor circuit, supports modern refrigerants such as R404A, R407A/C, R448A, R449A, and R507, and runs on 460 V 3-phase 60 Hz (T4B) power.

The unit’s copper-tube/aluminum-fin coil and galvanized-steel vertical housing provide high durability and efficient heat transfer under continuous-duty operation.

Technical Highlights (TVS Series):

Manufacturer: Trenton Refrigeration

Model: TVS035M8-HT4B-A3CQ78

Connected to: RCU 2 (Trenton TVS035M8 condensing unit)

Compressor Circuit: 3.5 HP Copeland Z-series scroll (via condensing unit)

Application: High / Medium Temperature (+35 °F to +40 °F room)

Electrical: 460 V / 3-Phase / 60 Hz (T4B)

Refrigerant Group: H8 (multi-refrigerant compatible)

Coil Construction: Copper-tube / aluminum-fin, factory-tested to 300 PSIG

Cabinet: Vertical galvanized-steel enclosure with top-discharge fans and access panels

Approx. Airflow: ~10 000 CFM (typical for 3.5 HP vertical scroll evaporator)

Mounting Location: Southwest corner of 37 °F Cold Pack Room

Condition: In-place installation; buyer responsible for lockout/tagout, refrigerant recovery, full disconnection, gas-line demo and capping, duct and piping removal, and rigging/removal per site and EPA standards.

The EVAP 3B system provides balanced temperature and airflow to the southern zone of the Cold Pack Room, ensuring uniform 37 °F conditions for processing and product staging.
