SB6018b: EVAP 5B – Trenton TLV325M4-S1D-C Low-Profile Air-Defrost Evaporator, 3-Fan, ≈ 2 785 CFM, 37 800 BTU/hr, 460 V 3-Phase – One Unit South of EVAP 5A in 55 °F Chilled Pack Room

This lot covers EVAP 5B – Trenton TLV325M4-S1D-C, a three-fan low-profile air-defrost evaporator located just south of EVAP 5A along the north wall of the 55 °F Chilled Pack Room.

The TLV series is Trenton’s compact medium-temperature cooler line, combining high air velocity and low clearance height—ideal for packing rooms and staging areas.

The TLV325M4-S1D-C provides ≈ 37 800 BTU/hr cooling at +25 °F SST and 10 °F TD, circulating roughly 2 785 CFM through three quiet axial fans. The “M4” coil uses 4-fins-per-inch spacing optimized for medium-temperature duty, and the “S1D” electrical code designates 460 V 3-phase 60 Hz operation. The “C” suffix indicates standard air defrost.

Technical Highlights (verified TLV series)

Manufacturer: Trenton Refrigeration

Model: TLV325M4-S1D-C

Cooling Capacity: ≈ 37 800 BTU/hr @ +25 °F SST, 10 °F TD

Airflow: ≈ 2 785 CFM (total 3 fans)

Fans: 3 × 460 V 3-phase axial motors

Defrost Type: Air defrost (C option)

Refrigerant Compatibility: R404A, R448A, R449A, R407A/C, R507

Coil: Copper tube / aluminum fin (4 FPI), pressure-tested to 300 PSIG
