SB6014b: EVAP 9 – Trenton TMP120MA Medium-Profile Air-Defrost Evaporator, Single Fan (~3 030 CFM, 460 V 3-Phase), 40 °F Seed Flat Storage (Connected to RCU 9)

This listing covers EVAP 8 – Trenton TMP120MA-32D, a single-fan, medium-profile, air-defrost evaporator located in the 55 °F Chilled Storage Room, paired with RCU 9 on the rooftop. The TMP series from Trenton Refrigeration is designed for medium-temperature cold-room and storage applications where reliability, airflow balance, and compact ceiling installation are required. The TMP120MA-32D model uses a single axial fan producing ≈ 3 030 CFM, draws ≈ 2.2 total fan amps, and provides a 13.5 °F temperature difference (TD) under standard conditions. The “M” designates a medium-temperature coil (approx. +25 °F SST), the “A” suffix indicates air defrost, and the “32D” indicates a 460 V 3-phase 60 Hz motor configuration. Technical Highlights (verified TMP series) Manufacturer: Trenton Refrigeration Model: TMP120MA-32D Connection: Linked to RCU 9 (Rooftop Condensing Unit) Airflow: ≈ 3 030 CFM (single axial fan) Fan Motor Load: ≈ 2.2 A @ 460 V 3-phase Cooling Capacity: ~12 000–13 500 BTU/hr (@ 13.5 °F TD, medium temp) Defrost Type: Air defrost (A suffix) Refrigerant Compatibility: R404A, R448A, R449A, R407A/C, R507 Coil: Copper-tube / aluminum-fin (6 FPI medium-temperature configuration) Cabinet: Galvanized-steel construction with hinged access panels and drain pan Electrical: 460 V 3-phase 60 Hz (32D) Dimensions (approx.): 65 in L × 28 in D × 20 in H | ~180 lb Mounting Location: Ceiling-hung in 55 °F Chilled Storage Room (most north unit connected to RCU 9) Decommissioning Notes: Unit remains installed. Buyer is responsible for full disconnection, gas-line demo and capping, rigging, and removal. Ductwork and associated piping connected to the RTU may be removed.
