SB6018a: EVAP 5A – Trenton TLV325M4-S1D-C Low-Profile Air-Defrost Evaporator, 3-Fan, ≈ 2 785 CFM, 37 800 BTU/hr Capacity, 460 V 3-Phase – North Wall of 55 °F Chilled Pack Room

This listing covers EVAP 5A – Trenton TLV325M4-S1D-C, a three-fan low-profile evaporator located at the north end of the 55 °F Chilled Pack Room. The TLV series from Trenton Refrigeration is engineered for medium-temperature (+25 °F to +55 °F) rooms where ceiling clearance is limited but strong air circulation and service access are required. Each TLV325M4-S1D-C unit features a 3-fan axial arrangement, air-defrost configuration, and a copper-tube/aluminum-fin coil rated for roughly 37 800 BTU/hr @ 10 °F TD. The “M4” denotes 4 FPI fin spacing for medium-temperature use, while “S1D” indicates 460 V 3-phase 60 Hz motor wiring. Verified Specifications (TLV325M4-S1D-C series): Cooling Capacity: ≈ 37 800 BTU/hr at +25 °F SST, 10 °F TD (medium temp) Airflow: ≈ 2 785 CFM (total 3 fans × ~930 CFM each) Fans: 3 × EC/PSC motors (460 V 3-phase 60 Hz) Defrost Type: Air defrost (“C” option) Refrigerants Supported: R404A, R448A, R449A, R407A/C, R507 (medium-temperature systems) Coil: Copper tube / aluminum fin (4 FPI) – factory pressure-tested to 300 PSIG Cabinet: Heavy-gauge galvanized steel with hinged drain pan and service access panels Dimensions (approx.): Length 78 in × Depth 27 in × Height 14 in Shipping Weight: ≈ 200 lb Electrical: 460 V / 3-Phase / 60 Hz (S1D) Mounting Location: Ceiling-hung on north wall of 55 °F Chilled Pack Room Condition: In-place installation; buyer responsible for lockout/tagout, refrigerant recovery, full disconnection, gas-line demo and capping, duct and piping removal, and rigging/removal per site and EPA standards.
