SB49: Stainless Food-Grade Conveyor System with Blue Modular Belt, Incline Feed Section, and Safety E-Stop – Wash-Down Rated for CEA or Food Processing

This lot is SB49, a stainless-steel food-grade conveyor system featuring a blue modular plastic belt with a powered incline feed section. It is part of the integrated tray washing and material-handling line, engineered for clean operation and easy sanitation in wet or temperature-controlled environments. The system includes an inclined infeed conveyor that transitions to a horizontal conveyor section, suitable for loading, inspection, or sorting. The belt surface and frame geometry are compliant with modern sanitary standards, ensuring full wash-down capability and preventing debris buildup. It uses FDA-compliant blue modular belting, standard in food, horticultural, and CEA environments for easy visual inspection and contamination control. System Features & Specifications: Construction: 304 stainless-steel frame and supports, open sanitary design Belt Type: Blue modular interlocking plastic food-grade belt (FDA-approved) Configuration: Incline feed section with side-guides, transitioning to horizontal conveyor section Drive System: Electric gearmotor drive (wash-down duty) Electrical: 480 V, 3-phase (verify plate) Safety: Emergency stop push-button at feed section, guarded belt edges, stainless mounting hardware Wiring: Stainless conduit and hygienic cable management along frame Feet/Base: Adjustable stainless legs with sealed bearings and leveling pads Wash-Down Rating: IP65/IP69K compatible materials Approx. Dimensions: ~20–25 ft overall length (combined feed and conveyor), ~24 in wide (belt), ~42 in discharge height (est.)
